Product Overview

The Square D by Schneider Electric 30 amp, 240 volt and 2 Pole Light Duty Safety Switch is designed for residential and agricultural applications in disconnecting power to workshops, hobby rooms, furnaces and garages. The switch is UL listed, File E2875 and meet or exceed the NEMA Standard KS1. For more than 100 years the Square D brand safety switch has been the unchallenged leader in the market. We've continued our tradition of innovation, developing new features that provide an unsurpassed level of performance, reliability, safety and ease of installation. This tradition has resulted in the Square D brand being preferred two to one over our closest competitor.
  • This Safety Switch is compatible with Square D transformers, panelboards, load centers, lighting, contactors, I-Line and residential QO or Homeline circuit breakers, NQ & NF panels *
  • 3-wire design with 2 blades and fuse holders and 1 neutral *
  • 120/240-Volt, indoor use only *
  • 30 Amp Maximum Rating *
  • NEMA 1 enclosure for indoor applications *
  • 1.5/3.0 Horsepower 240 VAC single phase (standard/maximum) *
  • The lugs on this device will accept (1) #14 - 8 AWG copper or (1) #12 - 8 AWG aluminum conductors per phase. *
  • This safety switch is compatible with cartridge fuses class H or J *
  • Neutral bar included *

Specifications

  • Brand Name: Square D
  • Product Type: Fuse Safety Switch
  • Amps: 30 ampere
  • CSA LIsted: No
  • Circuit Protection Type: Fusible
  • Depth: 4 inch
  • Height: 7.63 inch
  • Mounting Type: Surface Mount
  • Number of Poles: 2-Pole
  • Packaging Type: BOXED
  • Brand Name: Square D
  • UL Listed: Yes
  • Volts: 120 volt
  • Width: 5 inch
  • Indoor or Outdoor: INDOOR
  • Click here to see the Safety Data Sheets for this product.
