Product Overview

The Woodford Model 17 repair kit includes all parts to repair the faucet (excluding the rod and check valve). Use common household tools to repair. Repairs can be made without removing the faucet. 2-check valves included - beveled check valve used on model 17-faucets dated 04/98 or later, see packing nut stamp date to determine.
  • What's Included: (1) 30002 Handle Screw, (1) 30096 Metal Handle, (1) 30059 Packing Nut, (1) 30560 EPDM Packing, (1) 30421 Packing Washer, (1) 30418 Check Valve, (1) 30008 Valve Seat Rubber, (1) 30009 Retainer Screw, (1) RK-17VB Float Kit and (1) 30459 Bevel Check Valve
  • The choice of professionals
  • Round handle is die-cast powder-coated aluminum
  • Simple installation
  • Operating rod not included

Specifications

  • What's Included: (1) 30002 Handle Screw, (1) 30096 Metal Handle, (1) 30059 Packing Nut, (1) 30560 EPDM Packing, (1) 30421 Packing Washer, (1) 30418 Check Valve, (1) 30008 Valve Seat Rubber, (1) 30009 Retainer Screw, (1) RK-17VB Float Kit and (1) 30459 Bevel Check Valve
  • Brand Name: Woodford
  • Product Type: Repair Kit
  • End 1 Size: 1/2 inch
  • End 1 Type: MIP inch
  • End 2 Type: Hose
  • Frost-Proof: Yes
  • Handle Type: Round
  • Maximum Pressure: 125 pound per square inch
  • Maximum Temperature: 120 degree Fahrenheit
  • Material: Brass
  • Number in Package: 10 piece
  • Packaging Type: Bagged
  • Brand Name: Woodford
  • Turn Type: Multiturn
  • Lead Content: Less than 0.25%
  • Anti-Siphon: Yes
  • Click here to see the Safety Data Sheets for this product.
